Lewis Notation
Concept sheet | Science and Technology
Secondary
4
Lewis notation, sometimes called the electron dot structure, is used to represent the chemical symbol of an atom and its valence electrons.
In order to construct the Lewis notation of an atom, the number of valence electrons must be determined and precise rules must be followed. The resulting notation provides information about the chemical bonds that this atom can form with one or several other atoms.
Valence Electrons in an Atom
Valence electrons are the electrons located on the last electron shell of an atom.
The number of valence electrons in an atom can be determined by referring to the Rutherford-Bohr atomic model: simply count the electrons located on the last electron shell, which is the shell farthest from the nucleus.
Oxygen |(\text{O})| is an element with a total of 8 electrons. Of these 8 electrons, 6 are located on the last electron shell. Therefore, oxygen has 6 valence electrons.
The Rutherford-Bohr atomic model of oxygen (O)
Calcium |(\text{Ca})| is an element with a total of 20 electrons. Of these 20 electrons, 2 are located on the last electron shell. Therefore, calcium has 2 valence electrons.
The Rutherford-Bohr atomic model of calcium (Ca)
The number of valence electrons of an atom of a given element can also be determined by referring to the periodic table.
In this periodic table, some elements are highlighted. The number of valence electrons of these elements corresponds to the roman numeral indicating the group number to which they belong. For example, atoms in Group IA have 1 valence electron. Atoms in Group IIA have 2 valence electrons. Atoms in Group IIIA have 3, and so on.
Helium |(\text{He})| belongs to Group VIIIA, but it has only 2 valence electrons.
The Rutherford-Bohr atomic model of helium (He)
How many valence electrons does beryllium |(\text{Be})| have?
See solution
How many valence electrons does sulphur |(\text{S})| have?
See solution
Representing an Atom in Lewis Notation
The Lewis notation of a given atom includes its chemical symbol and its valence electron(s), symbolized by dots.
The valence electrons must be placed around the atom's symbol according to specific rules.
Lewis notation of a carbon atom (C)
-
There are four sides around the chemical symbol of an atom where the valence electrons can be placed.
-
A maximum of 2 electrons can be placed on each side.
-
The valence electrons are distributed one at a time on each side, before being placed in pairs.
Helium |(\text{He})| has 2 valence electrons. It is an exception to the last rule, because these electrons must be placed together in the following way.
Lewis notation of helium (He)
When representing the Lewis notation of an atom, some electrons can be found in pairs. They are called lone pairs of electrons. The other electrons are said to be unpaired.
The atom X has 1 lone pair of electrons and 3 unpaired electrons.
The lone pairs are placed parallel to the sides of the chemical symbol.
Represent the aluminum atom |(\text{Al})| using Lewis notation.
See solution
Represent the calcium atom |(\text{Ca})| using Lewis notation.
See solution
Represent the sulphur atom |(\text{S})| using Lewis notation.
See solution
Lewis Notation and Chemical Bonds (Secondary 4 EST)
In addition to representing individual atoms, Lewis notation is used to represent chemical bonds between atoms in molecules and in ionic compounds.
Ammonia |(\text{NH}_3)| is a molecule with one nitrogen atom |(\text{N})| bound to three hydrogen atoms |(\text{H}).| The atoms in this molecule are bound by covalent bonds.
The Lewis notation of ammonia looks as follows.
The Lewis notation of ammonia (NH3)
Sodium chloride |(\text{NaCl})| is an ionic compound composed of a sodium ion |(\text{Na}^+)| bound to a chlorine ion |(\text{Cl}^-).| The interaction between the positive charge of the sodium and the negative charge of the chlorine creates an ionic bond.
The Lewis notation for sodium chloride looks as follows.
The Lewis notation of sodium chloride (NaCl)
To learn more about the Lewis notation of molecules and ionic compounds, you can consult the different sections of the concept sheet on ionic and covalent bonds.
Video
What Is Lewis Notation?
Moments in the video:
- 00:00-Lewis notation
- 00:25-Valence electrons
- 00:50-Three rules to follow
- 01:15-Examples
- 02:22-Lewis notation and bonds
