Taping a Sheet of Paper to a Drawing Board
Concept sheet | Science and Technology
Secondary
1-4
Table of contents
The following tools and materials are required to attach a sheet of paper to the drawing board:
-
A sheet of white paper
-
A drawing board
-
A T-square
-
Tape
Tools and materials required to attach a sheet of paper to the drawing board
-
Place the sheet of white paper approximately in the centre of the drawing board.
-
Place the T-square on the sheet, pressing its head against the side of the drawing board. Right-handed people should press the T-square against the left edge of the drawing board, while left-handed people should press it against the right edge.
-
Align the bottom edge of the sheet with the top edge of the T-square.
-
Tape the top two corners of the sheet to the drawing board.
Taping the top corners of the sheet
-
Slide the T-square to approximately the middle of the sheet.
-
Tape the bottom two corners of the sheet to the drawing board and make sure it is attached securely.
Taping the bottom corners of the sheet
Taping a Sheet of Paper to a Drawing Board
Moments in the video:
- 00:00-Introduction
- 00:21-Place the sheet in the centre of the drawing board
- 00:24-Align the sheet with the edge of the T-square
- 00:44-Tape the 2 top corners
- 00:51-Slide the T-square
- 00:56-Tape the 2 bottom corners
